MORGAN 45
Built by Morgan Yachts (USA)
• Designed by Charles Morgan
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Sloop
First Built:
1966
Last Built:
1970
Number Built:
12
Dimensions
Length Overall (LOA):
13.92 m
Length Waterline (LWL):
9.58 m
Beam:
3.35 m
Draft (Max):
1.85 m
Weight & Ballast
Displacement:
11,340 kg
Ballast:
5,443 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
41.05 m²
Mainsail Area:
41.86 m²
Sail Area:
82.91 m²
Sail Area (reported):
82.96 m²
I (Fore Triangle Height):
15.39 m
J (Fore Triangle Base):
5.33 m
P (Mainsail Hoist):
13.56 m
E (Boom Length):
6.17 m
Est. Forestay Length:
16.29 m
Engine & Systems
Fuel Capacity:
189 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.51 knots
SA/Displacement (Calc):
16.77
SA/Displacement (Reported):
16.78
Ballast/Disp Ratio:
48.00%
Displacement/Length:
359.81
Comfort Ratio:
44.40
Capsize Screening:
1.51
S-Number:
1.33
Immersion:
221 kg/cm
Notes
Tooling was later used to build the STARRAT & JENKS 45.
