MORGAN 34
Built by Morgan Yachts (USA)
• Designed by Charles Morgan
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
First Built:
1965
Number Built:
400
Dimensions
Length Overall (LOA):
10.36 m
Length Waterline (LWL):
7.54 m
Beam:
3.05 m
Draft (Max):
2.41 m
Draft (Min):
0.99 m
Weight & Ballast
Displacement:
5,670 kg
Ballast:
2,359 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
25.08 m²
Mainsail Area:
25.53 m²
Sail Area:
50.62 m²
Sail Area (reported):
50.63 m²
I (Fore Triangle Height):
12.42 m
J (Fore Triangle Base):
4.04 m
P (Mainsail Hoist):
10.69 m
E (Boom Length):
4.78 m
Est. Forestay Length:
13.06 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
98 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
6.67 knots
SA/Displacement (Calc):
16.24
SA/Displacement (Reported):
16.25
Ballast/Disp Ratio:
41.60%
Displacement/Length:
368.08
Comfort Ratio:
32.68
Capsize Screening:
1.73
S-Number:
1.25
Immersion:
158 kg/cm
Notes
The MORGAN 34 was the first real production yacht from Morgan Yachts and among the most successful. A few later versions had a separated rudder on skeg. Some later boats were sold as kits. Early boats had bronze centerboards. Later on this was changed to fiberglass.
