MORGAN 41
Built by Morgan Yachts (USA)
• Designed by Charles Morgan
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
First Built:
1967
Last Built:
1972
Number Built:
350
Dimensions
Length Overall (LOA):
12.50 m
Length Waterline (LWL):
9.14 m
Beam:
3.43 m
Draft (Max):
2.87 m
Draft (Min):
1.27 m
Weight & Ballast
Displacement:
8,845 kg
Ballast:
4,082 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
36.56 m²
Mainsail Area:
35.36 m²
Sail Area:
71.92 m²
Sail Area (reported):
71.91 m²
I (Fore Triangle Height):
15.09 m
J (Fore Triangle Base):
4.85 m
P (Mainsail Hoist):
13.26 m
E (Boom Length):
5.33 m
Est. Forestay Length:
15.85 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Model:
Atomic 4
Engine Power:
20 HP
Fuel Capacity:
151 L
Water Capacity:
265 L
Performance Ratios
Hull Speed:
7.34 knots
SA/Displacement (Calc):
17.16
SA/Displacement (Reported):
17.16
Ballast/Disp Ratio:
46.15%
Displacement/Length:
322.42
Comfort Ratio:
36.03
Capsize Screening:
1.68
S-Number:
1.59
Immersion:
215 kg/cm
Notes
Westerbeke 4107 Diesel 40 hp. available as an option.
