MORGAN 30
Built by Morgan Yachts (USA)
• Designed by Charles Morgan
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/CB & spade rudder
Rigging Type:
Masthead Sloop
First Built:
1968
Last Built:
1971
Number Built:
320
Dimensions
Length Overall (LOA):
9.12 m
Length Waterline (LWL):
7.36 m
Beam:
2.82 m
Draft (Max):
2.18 m
Draft (Min):
1.07 m
Max Height:
13.03 m
Weight & Ballast
Displacement:
4,763 kg
Ballast:
2,041 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
21.74 m²
Mainsail Area:
21.61 m²
Sail Area:
43.35 m²
Sail Area (reported):
43.39 m²
I (Fore Triangle Height):
11.89 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
10.31 m
E (Boom Length):
4.19 m
Est. Forestay Length:
12.44 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Fuel Capacity:
53 L
Water Capacity:
140 L
Performance Ratios
Hull Speed:
6.59 knots
SA/Displacement (Calc):
15.62
SA/Displacement (Reported):
15.64
Ballast/Disp Ratio:
42.86%
Displacement/Length:
332.39
Comfort Ratio:
32.37
Capsize Screening:
1.69
S-Number:
1.42
Immersion:
143 kg/cm
Notes
A similar boat called the KK30 was available in kit form.
