MORGAN 24/25
Built by Morgan Yachts (USA)
• Designed by Charles Morgan Jr.
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/CB & spade rudder
Rigging Type:
Masthead Sloop
First Built:
1965
Last Built:
1976
Number Built:
460
Dimensions
Length Overall (LOA):
7.60 m
Length Waterline (LWL):
6.55 m
Beam:
2.44 m
Draft (Max):
2.13 m
Draft (Min):
0.85 m
Weight & Ballast
Displacement:
2,223 kg
Ballast:
862 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
14.04 m²
Mainsail Area:
14.42 m²
Sail Area:
28.46 m²
Sail Area (reported):
28.43 m²
I (Fore Triangle Height):
9.45 m
J (Fore Triangle Base):
2.97 m
P (Mainsail Hoist):
8.23 m
E (Boom Length):
3.51 m
Est. Forestay Length:
9.91 m
Engine & Systems
Water Capacity:
76 L
Performance Ratios
Hull Speed:
6.21 knots
SA/Displacement (Calc):
17.04
SA/Displacement (Reported):
17.02
Ballast/Disp Ratio:
38.78%
Displacement/Length:
220.11
Comfort Ratio:
21.06
Capsize Screening:
1.89
S-Number:
2.48
Immersion:
110 kg/cm
Notes
A Universal Atomic 4 inboard was avalable as an option.
