IMPRESSION 434 (ELAN)
Built by Elan Marine (SLO)
• Designed by Rob Humphreys
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
2005
Last Built:
2008
Dimensions
Length Overall (LOA):
13.41 m
Length Waterline (LWL):
11.45 m
Beam:
4.18 m
Draft (Max):
1.90 m
Max Height:
18.37 m
Weight & Ballast
Displacement:
10,900 kg
Ballast:
3,279 kg
Sail Plan
Foresail Area:
38.00 m²
Mainsail Area:
39.74 m²
Sail Area:
77.74 m²
Sail Area (reported):
86.21 m²
I (Fore Triangle Height):
15.90 m
J (Fore Triangle Base):
4.78 m
P (Mainsail Hoist):
14.80 m
E (Boom Length):
5.37 m
Est. Forestay Length:
16.61 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
D2-55
Engine Power:
55 HP
Fuel Capacity:
270 L
Water Capacity:
516 L
Performance Ratios
Hull Speed:
8.21 knots
SA/Displacement (Calc):
16.14
SA/Displacement (Reported):
17.90
Ballast/Disp Ratio:
30.09%
Displacement/Length:
202.29
Comfort Ratio:
28.77
Capsize Screening:
1.90
S-Number:
2.58
Immersion:
329 kg/cm
Notes
Shallow draft keel: 1.6m / 5.25ft.
