ELAN 310
Built by Elan Marine (SVN)
• Designed by Rob Humphreys
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & dual rudders
Rigging Type:
Fractional Sloop
First Built:
2009
Last Built:
2012
Dimensions
Length Overall (LOA):
9.55 m
Length Waterline (LWL):
8.71 m
Beam:
3.22 m
Draft (Max):
1.90 m
Weight & Ballast
Displacement:
3,750 kg
Ballast:
1,040 kg
Sail Plan
Foresail Area:
21.94 m²
Mainsail Area:
24.88 m²
Sail Area:
46.82 m²
Sail Area (reported):
53.62 m²
I (Fore Triangle Height):
12.25 m
J (Fore Triangle Base):
3.58 m
P (Mainsail Hoist):
12.05 m
E (Boom Length):
4.13 m
Est. Forestay Length:
12.76 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
18 HP
Fuel Capacity:
45 L
Water Capacity:
140 L
Performance Ratios
Hull Speed:
7.16 knots
SA/Displacement (Calc):
19.79
SA/Displacement (Reported):
22.66
Ballast/Disp Ratio:
27.74%
Displacement/Length:
158.09
Comfort Ratio:
18.82
Capsize Screening:
2.09
S-Number:
3.63
Immersion:
193 kg/cm
Notes
HULL LENGTH: 9.25m/30.35'
