ELAN 340
Built by Elan Marine
• Designed by Rob Humphreys
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
2006
Last Built:
2010
Dimensions
Length Overall (LOA):
9.99 m
Length Waterline (LWL):
9.38 m
Beam:
3.48 m
Draft (Max):
2.10 m
Max Height:
16.53 m
Weight & Ballast
Displacement:
5,000 kg
Ballast:
1,482 kg
Sail Plan
Foresail Area:
24.75 m²
Mainsail Area:
28.75 m²
Sail Area:
53.50 m²
Sail Area (reported):
53.51 m²
I (Fore Triangle Height):
13.49 m
J (Fore Triangle Base):
3.67 m
P (Mainsail Hoist):
12.78 m
E (Boom Length):
4.50 m
Est. Forestay Length:
13.98 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Power:
30 HP
Fuel Capacity:
95 L
Water Capacity:
201 L
Performance Ratios
Hull Speed:
7.44 knots
SA/Displacement (Calc):
18.67
SA/Displacement (Reported):
18.67
Ballast/Disp Ratio:
29.64%
Displacement/Length:
168.59
Comfort Ratio:
21.21
Capsize Screening:
2.05
S-Number:
3.32
Immersion:
224 kg/cm
Notes
Shallow draft: 1.95m/6.4' (lead keel available as an option)
