GRAMPIAN 34
Built by Grampian Marine Ltd. (CAN)
• Designed by Charles Angle/Axel Schmidt
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Ketch
First Built:
1972
Last Built:
1977
Number Built:
50
Dimensions
Length Overall (LOA):
10.24 m
Length Waterline (LWL):
8.07 m
Beam:
3.05 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
5,443 kg
Ballast:
2,345 kg
Sail Plan
Foresail Area:
18.73 m²
Mainsail Area:
18.39 m²
Sail Area:
37.12 m²
Sail Area (reported):
51.19 m²
I (Fore Triangle Height):
11.66 m
J (Fore Triangle Base):
3.21 m
P (Mainsail Hoist):
10.06 m
E (Boom Length):
3.66 m
PY (Mizzen Hoist):
7.82 m
EY (Mizzen Boom):
2.90 m
Est. Forestay Length:
12.09 m
Engine & Systems
Engine Make:
Volvo
Performance Ratios
Hull Speed:
6.89 knots
SA/Displacement (Calc):
12.24
SA/Displacement (Reported):
16.88
Ballast/Disp Ratio:
43.08%
Displacement/Length:
289.18
Comfort Ratio:
30.20
Capsize Screening:
1.75
S-Number:
1.41
Immersion:
169 kg/cm
Notes
Based on the earlier TRIANGLE 32, the GRAMPIAN 34 is entirely different from the later GRAMPIAN 2-34.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
