GRAMPIAN 22
Built by Grampian Marine Ltd. (CAN)
• Designed by George Cuthbertson
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
First Built:
1969
Last Built:
1971
Dimensions
Length Overall (LOA):
6.81 m
Length Waterline (LWL):
5.31 m
Beam:
2.13 m
Draft (Max):
1.14 m
Headroom:
1.04 m
Weight & Ballast
Displacement:
748 kg
Ballast:
386 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
7.32 m²
Mainsail Area:
12.06 m²
Sail Area:
19.38 m²
Sail Area (reported):
18.58 m²
I (Fore Triangle Height):
6.40 m
J (Fore Triangle Base):
2.29 m
P (Mainsail Hoist):
8.08 m
E (Boom Length):
2.99 m
Est. Forestay Length:
6.80 m
Engine & Systems
Performance Ratios
Hull Speed:
5.59 knots
SA/Displacement (Calc):
23.95
SA/Displacement (Reported):
22.97
Ballast/Disp Ratio:
51.52%
Displacement/Length:
139.35
Comfort Ratio:
10.10
Capsize Screening:
2.37
S-Number:
4.49
Immersion:
78 kg/cm
Notes
Also called the Grampian Classic 22. Originally called simply the CLASSIC 22. This design later appeared under a number of other names as well.
