GRAMPIAN 23
Built by Grampian Marine Ltd. (CAN)
• Designed by Alex McGruer
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Swing Keel
Rigging Type:
Masthead Sloop
First Built:
1971
Last Built:
1976
Number Built:
450
Dimensions
Length Overall (LOA):
7.09 m
Length Waterline (LWL):
6.38 m
Beam:
2.44 m
Draft (Max):
1.62 m
Draft (Min):
0.72 m
Max Height:
9.45 m
Weight & Ballast
Displacement:
1,451 kg
Ballast:
469 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
12.14 m²
Mainsail Area:
10.24 m²
Sail Area:
22.38 m²
Sail Area (reported):
22.39 m²
I (Fore Triangle Height):
8.05 m
J (Fore Triangle Base):
3.02 m
P (Mainsail Hoist):
7.22 m
E (Boom Length):
2.83 m
Est. Forestay Length:
8.60 m
Engine & Systems
Water Capacity:
76 L
Performance Ratios
Hull Speed:
6.13 knots
SA/Displacement (Calc):
17.80
SA/Displacement (Reported):
17.80
Ballast/Disp Ratio:
32.28%
Displacement/Length:
155.81
Comfort Ratio:
14.33
Capsize Screening:
2.17
S-Number:
3.40
Immersion:
107 kg/cm
Notes
The GRAMPIAN 23 was available with either a swing or fixed fin keel.
