GRAMPIAN 2-34
Built by Grampian Marine Ltd. (CAN)
• Designed by R. van der Staad
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1974
Last Built:
1977
Number Built:
50
Dimensions
Length Overall (LOA):
10.29 m
Length Waterline (LWL):
8.53 m
Beam:
3.05 m
Draft (Max):
1.60 m
Weight & Ballast
Displacement:
5,352 kg
Ballast:
2,345 kg
Sail Plan
Foresail Area:
27.80 m²
Mainsail Area:
20.62 m²
Sail Area:
48.43 m²
Sail Area (reported):
48.40 m²
I (Fore Triangle Height):
13.03 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
11.28 m
E (Boom Length):
3.66 m
Est. Forestay Length:
13.71 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD2B
Engine Power:
25 HP
Fuel Capacity:
98 L
Water Capacity:
170 L
Performance Ratios
Hull Speed:
7.09 knots
SA/Displacement (Calc):
16.15
SA/Displacement (Reported):
16.14
Ballast/Disp Ratio:
43.81%
Displacement/Length:
239.97
Comfort Ratio:
28.57
Capsize Screening:
1.76
S-Number:
2.19
Immersion:
179 kg/cm
Notes
Grampian built an ealier, and entirely different 34 based on the TRIANGLE 32. When Grampian went bankrupt in 1977, the molds for the 34-2 were sold, and few more were built elsewhere as the SEAFORTH 34.
