GRAMPIAN 28
Built by Grampian Marine Ltd. (CAN)
• Designed by Rolf van der Sleen
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1975
Number Built:
107
Dimensions
Length Overall (LOA):
8.53 m
Length Waterline (LWL):
7.47 m
Beam:
2.90 m
Draft (Max):
1.47 m
Weight & Ballast
Displacement:
3,130 kg
Ballast:
1,388 kg
Sail Plan
Foresail Area:
20.35 m²
Mainsail Area:
15.36 m²
Sail Area:
35.71 m²
Sail Area (reported):
35.67 m²
I (Fore Triangle Height):
11.13 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
9.60 m
E (Boom Length):
3.20 m
Est. Forestay Length:
11.71 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Fuel Capacity:
76 L
Water Capacity:
76 L
Performance Ratios
Hull Speed:
6.63 knots
SA/Displacement (Calc):
17.02
SA/Displacement (Reported):
17.00
Ballast/Disp Ratio:
44.35%
Displacement/Length:
209.46
Comfort Ratio:
20.81
Capsize Screening:
2.00
S-Number:
2.60
Immersion:
149 kg/cm
Notes
The later INTREPID 28, by Cape Dory, was based on this same design/tooling.
