ELAN 410
Built by Elan Marine (SLO)
• Designed by Rob Humphreys
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
2009
Last Built:
2012
Dimensions
Length Overall (LOA):
12.27 m
Length Waterline (LWL):
11.28 m
Beam:
3.91 m
Draft (Max):
2.20 m
Weight & Ballast
Displacement:
8,300 kg
Ballast:
2,779 kg
Sail Plan
Foresail Area:
38.57 m²
Mainsail Area:
43.86 m²
Sail Area:
82.43 m²
Sail Area (reported):
82.40 m²
I (Fore Triangle Height):
16.66 m
J (Fore Triangle Base):
4.63 m
P (Mainsail Hoist):
16.16 m
E (Boom Length):
5.43 m
Est. Forestay Length:
17.29 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
40 HP
Fuel Capacity:
144 L
Water Capacity:
356 L
Performance Ratios
Hull Speed:
8.15 knots
SA/Displacement (Calc):
20.52
SA/Displacement (Reported):
20.52
Ballast/Disp Ratio:
33.48%
Displacement/Length:
161.14
Comfort Ratio:
24.88
Capsize Screening:
1.95
S-Number:
3.67
Immersion:
303 kg/cm
Notes
Draft: deep keel 2.45 m/8.04'
