O'DAY 22
Built by O'Day Corp. (USA)
• Designed by C. Raymond Hunt and Associates
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Fractional Sloop
First Built:
1972
Last Built:
1983
Number Built:
3159
Dimensions
Length Overall (LOA):
6.61 m
Length Waterline (LWL):
5.77 m
Beam:
2.19 m
Draft (Max):
1.30 m
Draft (Min):
0.38 m
Max Height:
9.45 m
Weight & Ballast
Displacement:
990 kg
Ballast:
363 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
8.18 m²
Mainsail Area:
10.24 m²
Sail Area:
18.42 m²
Sail Area (reported):
18.42 m²
I (Fore Triangle Height):
6.71 m
J (Fore Triangle Base):
2.44 m
P (Mainsail Hoist):
7.47 m
E (Boom Length):
2.74 m
Est. Forestay Length:
7.14 m
Engine & Systems
Engine Type:
Outboard
Engine Power:
15 HP
Water Capacity:
57 L
Performance Ratios
Hull Speed:
5.83 knots
SA/Displacement (Calc):
18.89
SA/Displacement (Reported):
18.90
Ballast/Disp Ratio:
36.65%
Displacement/Length:
143.89
Comfort Ratio:
12.38
Capsize Screening:
2.21
S-Number:
3.74
Immersion:
87 kg/cm
Notes
One of the most successful of all O'Day models with more than 3000 built.
