HELSEN 22
Built by Helsen Yachts (USA)
• Designed by Johannes Helsen
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Swing Keel
Rigging Type:
Masthead Sloop
First Built:
1971
Dimensions
Length Overall (LOA):
6.71 m
Length Waterline (LWL):
5.79 m
Beam:
2.44 m
Draft (Max):
1.37 m
Draft (Min):
0.35 m
Weight & Ballast
Displacement:
998 kg
Ballast:
318 kg
Sail Plan
Foresail Area:
10.59 m²
Mainsail Area:
8.18 m²
Sail Area:
18.77 m²
Sail Area (reported):
18.77 m²
I (Fore Triangle Height):
7.32 m
J (Fore Triangle Base):
2.90 m
P (Mainsail Hoist):
6.10 m
E (Boom Length):
2.68 m
Est. Forestay Length:
7.87 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calc):
19.15
SA/Displacement (Reported):
19.15
Ballast/Disp Ratio:
31.82%
Displacement/Length:
143.19
Comfort Ratio:
10.70
Capsize Screening:
2.46
S-Number:
3.78
Immersion:
97 kg/cm
Notes
A later adaptation of this design became the WATKINS 23.
