ELAN 45
Built by Elan (SLOV)
• Designed by Rob Humphreys
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Masthead Sloop
First Built:
2000
Dimensions
Length Overall (LOA):
13.42 m
Length Waterline (LWL):
11.50 m
Beam:
4.19 m
Draft (Max):
2.10 m
Weight & Ballast
Displacement:
10,650 kg
Ballast:
3,600 kg
Sail Plan
Foresail Area:
45.93 m²
Mainsail Area:
42.41 m²
Sail Area:
88.34 m²
Sail Area (reported):
88.35 m²
I (Fore Triangle Height):
17.30 m
J (Fore Triangle Base):
5.31 m
P (Mainsail Hoist):
15.08 m
E (Boom Length):
5.62 m
Est. Forestay Length:
18.10 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
50 HP
Fuel Capacity:
220 L
Water Capacity:
549 L
Performance Ratios
Hull Speed:
8.23 knots
SA/Displacement (Calc):
18.63
SA/Displacement (Reported):
18.63
Ballast/Disp Ratio:
33.80%
Displacement/Length:
195.15
Comfort Ratio:
27.92
Capsize Screening:
1.92
S-Number:
2.96
Immersion:
331 kg/cm
Notes
Another version with a shorter boom is listed on brochure: E=16.33'.
