O'DAY 23-2
Built by O'Day Corp. (USA)
• Designed by C. Raymond Hunt and Associates
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
First Built:
1978
Last Built:
1984
Number Built:
1000
Dimensions
Length Overall (LOA):
6.93 m
Length Waterline (LWL):
5.94 m
Beam:
2.41 m
Draft (Max):
1.62 m
Draft (Min):
0.69 m
Headroom:
1.52 m
Max Height:
9.75 m
Weight & Ballast
Displacement:
1,554 kg
Ballast:
544 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
13.01 m²
Mainsail Area:
9.79 m²
Sail Area:
22.80 m²
Sail Area (reported):
22.85 m²
I (Fore Triangle Height):
8.53 m
J (Fore Triangle Base):
3.05 m
P (Mainsail Hoist):
7.14 m
E (Boom Length):
2.74 m
Est. Forestay Length:
9.06 m
Engine & Systems
Engine Type:
Outboard
Engine Power:
15 HP
Performance Ratios
Hull Speed:
5.92 knots
SA/Displacement (Calc):
17.33
SA/Displacement (Reported):
17.37
Ballast/Disp Ratio:
35.04%
Displacement/Length:
206.21
Comfort Ratio:
16.41
Capsize Screening:
2.10
S-Number:
2.67
Immersion:
99 kg/cm
Notes
Successor and similar to, the original O'DAY 23 (w/pop top companionway). The O'DAY 23 (all versions) was in production for more than 10 years and was one of the company's most popular models.
