O'DAY 19
Built by O'Day Corp. (USA)
• Designed by C. Raymond Hunt and Associates
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Fractional Sloop
First Built:
1979
Number Built:
525
Dimensions
Length Overall (LOA):
5.79 m
Length Waterline (LWL):
5.08 m
Beam:
2.36 m
Draft (Max):
1.32 m
Draft (Min):
0.30 m
Max Height:
8.94 m
Weight & Ballast
Displacement:
925 kg
Ballast:
136 kg
Sail Plan
Foresail Area:
7.15 m²
Mainsail Area:
9.45 m²
Sail Area:
16.60 m²
Sail Area (reported):
16.63 m²
I (Fore Triangle Height):
6.71 m
J (Fore Triangle Base):
2.13 m
P (Mainsail Hoist):
7.47 m
E (Boom Length):
2.53 m
Est. Forestay Length:
7.04 m
Engine & Systems
Performance Ratios
Hull Speed:
5.47 knots
SA/Displacement (Calc):
17.81
SA/Displacement (Reported):
17.85
Ballast/Disp Ratio:
14.71%
Displacement/Length:
196.60
Comfort Ratio:
11.86
Capsize Screening:
2.45
S-Number:
2.84
Immersion:
82 kg/cm
Notes
Centerboard weight = 52 lbs / 23.6 kg
