MORGAN 45-4
Built by Morgan Yachts (USA)
• Designed by Nelson/Marek
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1983
Dimensions
Length Overall (LOA):
13.82 m
Length Waterline (LWL):
11.20 m
Beam:
4.09 m
Draft (Max):
2.41 m
Weight & Ballast
Displacement:
10,206 kg
Ballast:
4,513 kg
Sail Plan
Foresail Area:
46.99 m²
Mainsail Area:
36.79 m²
Sail Area:
83.78 m²
Sail Area (reported):
83.80 m²
I (Fore Triangle Height):
17.13 m
J (Fore Triangle Base):
5.49 m
P (Mainsail Hoist):
15.09 m
E (Boom Length):
4.88 m
Est. Forestay Length:
17.99 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Model:
5432
Engine Power:
44 HP
Fuel Capacity:
379 L
Water Capacity:
780 L
Performance Ratios
Hull Speed:
8.12 knots
SA/Displacement (Calc):
18.17
SA/Displacement (Reported):
18.18
Ballast/Disp Ratio:
44.22%
Displacement/Length:
202.38
Comfort Ratio:
27.84
Capsize Screening:
1.91
S-Number:
2.81
Immersion:
315 kg/cm
Notes
Shoal draft and keel/cb versions available.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
