KETTENBURG 32
Built by Kettenburg Marine/Whittaker Corp.
• Designed by Alan Payne
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1975
Last Built:
1978
Dimensions
Length Overall (LOA):
9.60 m
Length Waterline (LWL):
7.24 m
Beam:
3.10 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
4,763 kg
Ballast:
2,077 kg
Sail Plan
Foresail Area:
24.53 m²
Mainsail Area:
17.93 m²
Sail Area:
42.46 m²
Sail Area (reported):
42.36 m²
I (Fore Triangle Height):
12.24 m
J (Fore Triangle Base):
4.01 m
P (Mainsail Hoist):
10.70 m
E (Boom Length):
3.35 m
Est. Forestay Length:
12.88 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD-7A
Engine Power:
13 HP
Fuel Capacity:
114 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
6.53 knots
SA/Displacement (Calc):
15.30
SA/Displacement (Reported):
15.27
Ballast/Disp Ratio:
43.62%
Displacement/Length:
349.91
Comfort Ratio:
28.33
Capsize Screening:
1.86
S-Number:
1.30
Immersion:
154 kg/cm
Notes
The hull for the KETTENBURG 32 (also called the KETTENBURG 9.6) was molded by Columbia Yachts and is similar to the earlier COLUMBIA 9.6.
