LAGUNA 22
Built by Laguna Yachts (USA)
• Designed by Shad Turner
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
First Built:
1983
Last Built:
1987
Dimensions
Length Overall (LOA):
6.58 m
Length Waterline (LWL):
5.79 m
Beam:
2.44 m
Draft (Max):
0.89 m
Weight & Ballast
Displacement:
1,034 kg
Ballast:
408 kg
Sail Plan
Foresail Area:
9.75 m²
Mainsail Area:
9.35 m²
Sail Area:
19.10 m²
Sail Area (reported):
19.14 m²
I (Fore Triangle Height):
7.32 m
J (Fore Triangle Base):
2.67 m
P (Mainsail Hoist):
7.01 m
E (Boom Length):
2.67 m
Est. Forestay Length:
7.79 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calc):
19.04
SA/Displacement (Reported):
19.07
Ballast/Disp Ratio:
39.47%
Displacement/Length:
148.40
Comfort Ratio:
11.16
Capsize Screening:
2.43
S-Number:
3.68
Immersion:
97 kg/cm
Notes
The LAGUNA 22 is similar to the earlier WINDROSE 22 and the BALBOA 22.
