IRWIN 39 CITATION
Built by Irwin Yachts (USA)
• Designed by Ted Irwin
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1979
Dimensions
Length Overall (LOA):
12.12 m
Length Waterline (LWL):
9.50 m
Beam:
3.71 m
Draft (Max):
1.91 m
Max Height:
17.27 m
Weight & Ballast
Displacement:
7,661 kg
Ballast:
2,948 kg
Sail Plan
Foresail Area:
39.86 m²
Mainsail Area:
31.52 m²
Sail Area:
71.37 m²
Sail Area (reported):
71.44 m²
I (Fore Triangle Height):
15.85 m
J (Fore Triangle Base):
5.03 m
P (Mainsail Hoist):
14.02 m
E (Boom Length):
4.50 m
Est. Forestay Length:
16.63 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM20
Fuel Capacity:
151 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.48 knots
SA/Displacement (Calc):
18.74
SA/Displacement (Reported):
18.76
Ballast/Disp Ratio:
38.48%
Displacement/Length:
248.98
Comfort Ratio:
27.74
Capsize Screening:
1.90
S-Number:
2.34
Immersion:
242 kg/cm
Notes
Fixed keel shoal draft: 4.3'
