IRWIN 40 MKII
Built by Irwin Yachts (USA)
• Designed by Ted Irwin
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1980
Dimensions
Length Overall (LOA):
12.44 m
Length Waterline (LWL):
9.50 m
Beam:
3.71 m
Draft (Max):
1.91 m
Weight & Ballast
Displacement:
7,661 kg
Ballast:
2,948 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
38.32 m²
Mainsail Area:
30.15 m²
Sail Area:
68.47 m²
Sail Area (reported):
68.47 m²
I (Fore Triangle Height):
15.24 m
J (Fore Triangle Base):
5.03 m
P (Mainsail Hoist):
13.41 m
E (Boom Length):
4.50 m
Est. Forestay Length:
16.05 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2QM20
Fuel Capacity:
151 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.48 knots
SA/Displacement (Calc):
17.98
SA/Displacement (Reported):
17.98
Ballast/Disp Ratio:
38.48%
Displacement/Length:
248.98
Comfort Ratio:
27.47
Capsize Screening:
1.90
S-Number:
2.28
Immersion:
242 kg/cm
Notes
Shoal Draft vers: 4.25' Bal. 7000 lbs.
