IRWIN 30
Built by Irwin Yachts (USA)
• Designed by Ted Irwin
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1976
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
8.21 m
Beam:
3.10 m
Draft (Max):
1.52 m
Max Height:
13.87 m
Weight & Ballast
Displacement:
4,173 kg
Ballast:
1,860 kg
Sail Plan
Foresail Area:
26.14 m²
Mainsail Area:
17.88 m²
Sail Area:
44.02 m²
Sail Area (reported):
44.04 m²
I (Fore Triangle Height):
12.70 m
J (Fore Triangle Base):
4.11 m
P (Mainsail Hoist):
10.67 m
E (Boom Length):
3.35 m
Est. Forestay Length:
13.35 m
Engine & Systems
Performance Ratios
Hull Speed:
6.95 knots
SA/Displacement (Calc):
17.32
SA/Displacement (Reported):
17.33
Ballast/Disp Ratio:
44.57%
Displacement/Length:
210.53
Comfort Ratio:
23.25
Capsize Screening:
1.94
S-Number:
2.62
Immersion:
175 kg/cm
Notes
Shoal draft version: 3.92'.
