GK 34 (WESTERLY)
Built by Westerly Marine Ltd. (UK)
• Designed by Ed Dubois
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
First Built:
1980
Last Built:
1981
Number Built:
17
Dimensions
Length Overall (LOA):
10.36 m
Length Waterline (LWL):
8.43 m
Beam:
3.43 m
Draft (Max):
1.91 m
Weight & Ballast
Displacement:
3,810 kg
Ballast:
2,087 kg
Ballast Type:
Cast iron
Sail Plan
Foresail Area:
21.87 m²
Mainsail Area:
29.50 m²
Sail Area:
51.37 m²
Sail Area (reported):
47.61 m²
I (Fore Triangle Height):
11.77 m
J (Fore Triangle Base):
3.72 m
P (Mainsail Hoist):
13.44 m
E (Boom Length):
4.39 m
Est. Forestay Length:
12.34 m
Engine & Systems
Engine Make:
Bukh
Engine Type:
Diesel
Engine Model:
DV20ME
Engine Power:
20 HP
Fuel Capacity:
57 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
7.05 knots
SA/Displacement (Calc):
21.48
SA/Displacement (Reported):
19.91
Ballast/Disp Ratio:
54.76%
Displacement/Length:
177.01
Comfort Ratio:
17.48
Capsize Screening:
2.22
S-Number:
3.54
Immersion:
199 kg/cm
Notes
2 boats were made with Kevlar hulls (known as the "Grand Prix"). Plus lead keel and 6.58 ft / 2 m draft in the case of the Grand Prix models.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
