KONSORT 29 (WESTERLY)
Built by Westerly Marine Ltd. (UK)
• Designed by Laurent Giles
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
First Built:
1979
Last Built:
1991
Number Built:
704
Dimensions
Length Overall (LOA):
8.79 m
Length Waterline (LWL):
7.77 m
Beam:
3.28 m
Draft (Max):
1.62 m
Max Height:
10.90 m
Weight & Ballast
Displacement:
4,178 kg
Ballast:
1,451 kg
Sail Plan
Foresail Area:
19.60 m²
Mainsail Area:
16.72 m²
Sail Area:
36.32 m²
Sail Area (reported):
36.33 m²
I (Fore Triangle Height):
11.43 m
J (Fore Triangle Base):
3.43 m
P (Mainsail Hoist):
9.54 m
E (Boom Length):
3.51 m
Est. Forestay Length:
11.93 m
Engine & Systems
Engine Make:
Bukh
Engine Type:
Diesel
Engine Model:
DV20ME
Engine Power:
20 HP
Fuel Capacity:
68 L
Water Capacity:
151 L
Performance Ratios
Hull Speed:
6.77 knots
SA/Displacement (Calc):
14.28
SA/Displacement (Reported):
14.28
Ballast/Disp Ratio:
34.74%
Displacement/Length:
247.99
Comfort Ratio:
22.72
Capsize Screening:
2.05
S-Number:
1.92
Immersion:
175 kg/cm
Notes
Twin Keel model - draft: 3.2'/.98m. A Pilothouse 'DUO' model was also available.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
