GARRETT 40 GPR MH
Built by Garrett Marine
• Designed by Bruce Farr
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
First Built:
1983
Dimensions
Length Overall (LOA):
12.09 m
Length Waterline (LWL):
9.53 m
Beam:
4.04 m
Draft (Max):
2.29 m
Weight & Ballast
Displacement:
6,305 kg
Ballast:
3,221 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
36.19 m²
Mainsail Area:
32.53 m²
Sail Area:
68.72 m²
Sail Area (reported):
69.40 m²
I (Fore Triangle Height):
15.80 m
J (Fore Triangle Base):
4.58 m
P (Mainsail Hoist):
13.84 m
E (Boom Length):
4.70 m
Est. Forestay Length:
16.45 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Performance Ratios
Hull Speed:
7.49 knots
SA/Displacement (Calc):
20.55
SA/Displacement (Reported):
20.75
Ballast/Disp Ratio:
51.08%
Displacement/Length:
203.34
Comfort Ratio:
20.37
Capsize Screening:
2.21
S-Number:
3.06
Immersion:
264 kg/cm
Notes
IOR 1 ton racer.
