GARRETT 40 GPR FR
Built by Garrett Marine
• Designed by Bruce Farr
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
First Built:
1983
Dimensions
Length Overall (LOA):
12.09 m
Length Waterline (LWL):
9.53 m
Beam:
4.04 m
Draft (Max):
2.29 m
Weight & Ballast
Displacement:
6,305 kg
Ballast:
3,221 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
30.65 m²
Mainsail Area:
45.23 m²
Sail Area:
75.88 m²
Sail Area (reported):
76.37 m²
I (Fore Triangle Height):
14.33 m
J (Fore Triangle Base):
4.28 m
P (Mainsail Hoist):
15.87 m
E (Boom Length):
5.70 m
Est. Forestay Length:
14.95 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Performance Ratios
Hull Speed:
7.49 knots
SA/Displacement (Calc):
22.69
SA/Displacement (Reported):
22.83
Ballast/Disp Ratio:
51.08%
Displacement/Length:
203.34
Comfort Ratio:
20.37
Capsize Screening:
2.21
S-Number:
3.27
Immersion:
264 kg/cm
Notes
IOR 1 ton racer.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
