FREEDOM 36
Built by Tillotson Pearson Inc, (USA)
• Designed by Gary Mull
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Frac. Sloop (Free standing)
First Built:
1985
Dimensions
Length Overall (LOA):
11.10 m
Length Waterline (LWL):
9.34 m
Beam:
3.81 m
Draft (Max):
1.37 m
Headroom:
1.93 m
Max Height:
16.92 m
Weight & Ballast
Displacement:
6,518 kg
Ballast:
2,948 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
17.81 m²
Mainsail Area:
35.02 m²
Sail Area:
52.83 m²
Sail Area (reported):
63.64 m²
I (Fore Triangle Height):
10.16 m
J (Fore Triangle Base):
3.51 m
P (Mainsail Hoist):
13.87 m
E (Boom Length):
5.05 m
Est. Forestay Length:
10.75 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3GM
Engine Power:
27 HP
Fuel Capacity:
132 L
Water Capacity:
242 L
Performance Ratios
Hull Speed:
7.42 knots
SA/Displacement (Calc):
15.45
SA/Displacement (Reported):
18.61
Ballast/Disp Ratio:
45.23%
Displacement/Length:
223.24
Comfort Ratio:
23.74
Capsize Screening:
2.06
S-Number:
2.27
Immersion:
244 kg/cm
Notes
Deep keel: Draft - 6.0'/1.83m; Ballast - 5,530 lbs / 5,530 kg; Displacement - 13,400 lbs / 6,078 kg
