FREEDOM 30
Built by Tillotson Pearson Inc, (USA)
• Designed by Gary Mull
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Frac. Sloop (Free standing)
First Built:
1986
Dimensions
Length Overall (LOA):
9.13 m
Length Waterline (LWL):
7.75 m
Beam:
3.28 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
3,475 kg
Ballast:
1,429 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
12.96 m²
Mainsail Area:
24.66 m²
Sail Area:
37.62 m²
Sail Area (reported):
37.63 m²
I (Fore Triangle Height):
8.65 m
J (Fore Triangle Base):
3.00 m
P (Mainsail Hoist):
11.63 m
E (Boom Length):
4.24 m
Est. Forestay Length:
9.15 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM20F
Engine Power:
18 HP
Fuel Capacity:
76 L
Water Capacity:
189 L
Performance Ratios
Hull Speed:
6.76 knots
SA/Displacement (Calc):
16.72
SA/Displacement (Reported):
16.73
Ballast/Disp Ratio:
41.12%
Displacement/Length:
208.19
Comfort Ratio:
18.69
Capsize Screening:
2.18
S-Number:
2.58
Immersion:
174 kg/cm
Notes
Renamed FREEDOM 32 (here designated as FREEDOM 32-2) in 1988 (boarding/swimming platform added to stern).
