ERICSON 34
Built by Ericson Yachts (USA)
• Designed by Bruce King
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1978
Dimensions
Length Overall (LOA):
10.40 m
Length Waterline (LWL):
8.80 m
Beam:
3.28 m
Draft (Max):
1.80 m
Weight & Ballast
Displacement:
4,536 kg
Ballast:
2,268 kg
Sail Plan
Foresail Area:
27.62 m²
Mainsail Area:
18.30 m²
Sail Area:
45.93 m²
Sail Area (reported):
45.89 m²
I (Fore Triangle Height):
13.11 m
J (Fore Triangle Base):
4.22 m
P (Mainsail Hoist):
11.58 m
E (Boom Length):
3.16 m
Est. Forestay Length:
13.77 m
Engine & Systems
Performance Ratios
Hull Speed:
7.20 knots
SA/Displacement (Calc):
17.10
SA/Displacement (Reported):
17.09
Ballast/Disp Ratio:
50.00%
Displacement/Length:
185.53
Comfort Ratio:
21.47
Capsize Screening:
2.00
S-Number:
2.90
Immersion:
198 kg/cm
Notes
Sometimes referred to as the 34X, this is the 'blister' decked version of the ERICSON 34 designed to the IOR rule. The 34T shares the same hull but with a trunk cabin. A later boat, the ERICSON 34-2, is a completely different design.
