ORION 35
Built by Orion Yacht-Artimus Corp (USA)
• Designed by Sparkman & Stephens
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1978
Dimensions
Length Overall (LOA):
10.52 m
Length Waterline (LWL):
8.76 m
Beam:
3.30 m
Draft (Max):
1.83 m
Weight & Ballast
Displacement:
4,479 kg
Ballast:
2,132 kg
Sail Plan
Foresail Area:
28.61 m²
Mainsail Area:
19.10 m²
Sail Area:
47.71 m²
Sail Area (reported):
47.57 m²
I (Fore Triangle Height):
13.41 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
12.02 m
E (Boom Length):
3.18 m
Est. Forestay Length:
14.07 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Power:
24 HP
Fuel Capacity:
132 L
Water Capacity:
246 L
Performance Ratios
Hull Speed:
7.18 knots
SA/Displacement (Calc):
17.91
SA/Displacement (Reported):
17.86
Ballast/Disp Ratio:
47.59%
Displacement/Length:
185.51
Comfort Ratio:
20.97
Capsize Screening:
2.02
S-Number:
3.00
Immersion:
199 kg/cm
Notes
Shoal draft version - draft: 4.5'. Designed as IOR 3/4 ton.
