DOLPHIN 24 (S&S)
Built by O'Day Corp. (USA)
• Designed by Sparkman & Stephens
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
First Built:
1959
Last Built:
1967
Number Built:
36
Dimensions
Length Overall (LOA):
7.36 m
Length Waterline (LWL):
5.79 m
Beam:
2.34 m
Draft (Max):
1.58 m
Draft (Min):
0.86 m
Weight & Ballast
Displacement:
1,928 kg
Ballast:
748 kg
Sail Plan
Foresail Area:
12.86 m²
Mainsail Area:
14.52 m²
Sail Area:
27.37 m²
Sail Area (reported):
27.59 m²
I (Fore Triangle Height):
9.37 m
J (Fore Triangle Base):
2.74 m
P (Mainsail Hoist):
8.05 m
E (Boom Length):
3.61 m
Est. Forestay Length:
9.77 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calc):
18.02
SA/Displacement (Reported):
18.16
Ballast/Disp Ratio:
38.82%
Displacement/Length:
276.62
Comfort Ratio:
21.18
Capsize Screening:
1.90
S-Number:
2.02
Immersion:
93 kg/cm
Notes
S&S design #1497. (At this time, William Shaw was an employee with S&S.)
