JAVELIN 14 (FOX)
Built by O'Day Corp. (USA)
• Designed by Uffa Fox
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Centerboard Dinghy
Rigging Type:
Fractional Sloop
First Built:
1960
Number Built:
5100
Dimensions
Length Overall (LOA):
4.27 m
Length Waterline (LWL):
4.01 m
Beam:
1.73 m
Draft (Max):
1.17 m
Draft (Min):
0.15 m
Max Height:
7.03 m
Weight & Ballast
Displacement:
215 kg
Ballast:
22 kg
Ballast Type:
Galv. steel
Sail Plan
Sail Area (reported):
11.61 m²
Engine & Systems
Performance Ratios
Hull Speed:
4.86 knots
SA/Displacement (Reported):
32.90
Ballast/Disp Ratio:
10.32%
Displacement/Length:
92.83
Comfort Ratio:
5.42
Capsize Screening:
2.91
Immersion:
48 kg/cm
Notes
Displacement = hull weight only.
