DOLPHIN 24 (YANKEE)
Built by Yankee Yachts Inc. (USA)
• Designed by Sparkman & Stephens
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
First Built:
1968
Dimensions
Length Overall (LOA):
7.36 m
Length Waterline (LWL):
5.79 m
Beam:
2.34 m
Draft (Max):
1.57 m
Draft (Min):
0.86 m
Weight & Ballast
Displacement:
1,928 kg
Ballast:
748 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
12.86 m²
Mainsail Area:
14.52 m²
Sail Area:
27.37 m²
Sail Area (reported):
27.41 m²
I (Fore Triangle Height):
9.37 m
J (Fore Triangle Base):
2.74 m
P (Mainsail Hoist):
8.05 m
E (Boom Length):
3.61 m
Est. Forestay Length:
9.77 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calc):
18.02
SA/Displacement (Reported):
18.04
Ballast/Disp Ratio:
38.82%
Displacement/Length:
276.62
Comfort Ratio:
21.18
Capsize Screening:
1.90
S-Number:
2.02
Immersion:
93 kg/cm
Notes
From a 1959 S&S design (#1497) to the MORC rule. Similar to the O'Day version. (The earlier hulls for the YANKEE DOLPHIN where molded by O'Day. Yankee eventually used one of these to built its own mold.) This design, with some modifications, was built by a number of builders. A wood predecessor was called the MERMAID 24.
