RANGER 20
Built by Ranger Fiberglass Boats (USA)
• Designed by Raymond Richards
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Fractional Sloop
First Built:
1972
Number Built:
600
Dimensions
Length Overall (LOA):
6.10 m
Length Waterline (LWL):
4.88 m
Beam:
2.40 m
Draft (Max):
0.94 m
Draft (Min):
0.57 m
Weight & Ballast
Displacement:
680 kg
Ballast:
249 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
9.51 m²
Mainsail Area:
8.36 m²
Sail Area:
17.87 m²
Sail Area (reported):
17.74 m²
I (Fore Triangle Height):
7.19 m
J (Fore Triangle Base):
2.65 m
P (Mainsail Hoist):
6.86 m
E (Boom Length):
2.44 m
Est. Forestay Length:
7.66 m
Engine & Systems
Performance Ratios
Hull Speed:
5.36 knots
SA/Displacement (Calc):
23.53
SA/Displacement (Reported):
23.37
Ballast/Disp Ratio:
36.67%
Displacement/Length:
163.49
Comfort Ratio:
8.63
Capsize Screening:
2.75
S-Number:
3.99
Immersion:
80 kg/cm
Notes
Later built by Intermountain Design of Utah, USA.
