RAFIKI 35
Built by Lien Hwa (TAIWAN)
• Designed by Stan Huntingford
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Long Keel
Rigging Type:
Cutter
First Built:
1977
Last Built:
1992
Number Built:
32
Dimensions
Length Overall (LOA):
10.57 m
Length Waterline (LWL):
8.38 m
Beam:
3.30 m
Draft (Max):
1.37 m
Weight & Ballast
Displacement:
7,484 kg
Ballast:
3,084 kg
Sail Plan
Foresail Area:
26.65 m²
Mainsail Area:
22.44 m²
Sail Area:
49.09 m²
Sail Area (reported):
48.77 m²
I (Fore Triangle Height):
12.95 m
J (Fore Triangle Base):
4.11 m
P (Mainsail Hoist):
10.52 m
E (Boom Length):
4.27 m
Est. Forestay Length:
13.59 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD 2B
Engine Power:
28 HP
Performance Ratios
Hull Speed:
7.03 knots
SA/Displacement (Calc):
13.09
SA/Displacement (Reported):
13.01
Ballast/Disp Ratio:
41.21%
Displacement/Length:
354.19
Comfort Ratio:
36.01
Capsize Screening:
1.70
S-Number:
1.12
Immersion:
190 kg/cm
Notes
Thanks to 'Tom' (RAFIKI 35 Hull #7 - 1978) - Moonraker) for providing corrected information.
