JASON 35
Built by Miller Marine Corp. (USA)
• Designed by Ted Brewer
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Cutter
First Built:
1972
Number Built:
40
Dimensions
Length Overall (LOA):
10.52 m
Length Waterline (LWL):
8.33 m
Beam:
3.40 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
7,620 kg
Ballast:
2,812 kg
Sail Plan
Sail Area (reported):
58.90 m²
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4-108M
Engine Power:
52 HP
Fuel Capacity:
102 L
Water Capacity:
360 L
Performance Ratios
Hull Speed:
7.01 knots
SA/Displacement (Reported):
15.52
Ballast/Disp Ratio:
36.90%
Displacement/Length:
367.40
Comfort Ratio:
35.40
Capsize Screening:
1.75
Immersion:
195 kg/cm
Notes
Thanks to designer Ted Brewer for providing corrections and images.
