PIERCE ARROW 18
Built by Freedom Yachts Ltd. (USA)
• Designed by Mark Leonard
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
First Built:
1982
Last Built:
1985
Dimensions
Length Overall (LOA):
5.66 m
Length Waterline (LWL):
5.08 m
Beam:
2.44 m
Draft (Max):
1.22 m
Draft (Min):
0.23 m
Weight & Ballast
Displacement:
499 kg
Ballast:
181 kg
Sail Plan
Sail Area (reported):
17.19 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.47 knots
SA/Displacement (Reported):
27.83
Ballast/Disp Ratio:
36.36%
Displacement/Length:
106.01
Comfort Ratio:
6.18
Capsize Screening:
3.10
Immersion:
85 kg/cm
Notes
Freedom Yachts, Rockford, Ill. (not to be confused with Freedom Yachts founded by Garry Hoyt).
