FREEDOM 35 (PEDRICK)
Built by Freedom Yachts (USA)
• Designed by David Pedrick
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Frac. Sloop (Free standing)
First Built:
1993
Dimensions
Length Overall (LOA):
10.79 m
Length Waterline (LWL):
9.11 m
Beam:
3.66 m
Draft (Max):
1.98 m
Max Height:
16.61 m
Weight & Ballast
Displacement:
6,627 kg
Ballast:
2,025 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
21.31 m²
Mainsail Area:
35.27 m²
Sail Area:
56.59 m²
Sail Area (reported):
56.58 m²
I (Fore Triangle Height):
12.16 m
J (Fore Triangle Base):
3.51 m
P (Mainsail Hoist):
13.78 m
E (Boom Length):
5.12 m
Est. Forestay Length:
12.66 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3GM30F
Engine Power:
27 HP
Fuel Capacity:
132 L
Water Capacity:
265 L
Performance Ratios
Hull Speed:
7.33 knots
SA/Displacement (Calc):
16.37
SA/Displacement (Reported):
16.36
Ballast/Disp Ratio:
30.56%
Displacement/Length:
244.02
Comfort Ratio:
26.15
Capsize Screening:
1.97
S-Number:
2.17
Immersion:
229 kg/cm
Notes
Winged keel version - draft:4.5'
