OUTLAW 23 (MILNE)
Built by Sail Craft Ltd. (CAN)
• Designed by Peter Milne
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
First Built:
1962
Dimensions
Length Overall (LOA):
6.80 m
Length Waterline (LWL):
5.79 m
Beam:
2.40 m
Draft (Max):
0.91 m
Draft (Min):
0.38 m
Weight & Ballast
Displacement:
748 kg
Ballast:
227 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
7.34 m²
Mainsail Area:
11.72 m²
Sail Area:
19.06 m²
Sail Area (reported):
19.05 m²
I (Fore Triangle Height):
7.19 m
J (Fore Triangle Base):
2.04 m
P (Mainsail Hoist):
7.92 m
E (Boom Length):
2.96 m
Est. Forestay Length:
7.48 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calc):
23.56
SA/Displacement (Reported):
23.54
Ballast/Disp Ratio:
30.30%
Displacement/Length:
107.39
Comfort Ratio:
8.17
Capsize Screening:
2.67
S-Number:
5.11
Immersion:
95 kg/cm
Notes
An early wooden version of this design has been mentioned in varioius periodicals but the details have been difficult to find.
