O'DAY 40
Built by Lear Siegler Marine (USA)
• Designed by Briand/Raymond Hunt Associates
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1986
Number Built:
180
Dimensions
Length Overall (LOA):
12.06 m
Length Waterline (LWL):
10.21 m
Beam:
3.84 m
Draft (Max):
1.92 m
Weight & Ballast
Displacement:
8,165 kg
Ballast:
2,994 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
35.76 m²
Mainsail Area:
29.15 m²
Sail Area:
64.91 m²
Sail Area (reported):
64.94 m²
I (Fore Triangle Height):
15.43 m
J (Fore Triangle Base):
4.64 m
P (Mainsail Hoist):
13.50 m
E (Boom Length):
4.32 m
Est. Forestay Length:
16.11 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Engine Power:
46 HP
Fuel Capacity:
151 L
Water Capacity:
405 L
Performance Ratios
Hull Speed:
7.76 knots
SA/Displacement (Calc):
16.34
SA/Displacement (Reported):
16.34
Ballast/Disp Ratio:
36.67%
Displacement/Length:
213.74
Comfort Ratio:
26.96
Capsize Screening:
1.93
S-Number:
2.47
Immersion:
269 kg/cm
Notes
Based on the SUN FIZZ 39 > O'DAY 39 by Briand, with modifications by Hunt Associates. Differences from the O'DAY 39: Extended 'suger scoop' stern, different interior layout.
