O'DAY 192
Built by Lear Siegler Marine (USA)
• Designed by C. Raymond Hunt and Associates
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Fractional Sloop
First Built:
1984
Last Built:
1997
Dimensions
Length Overall (LOA):
5.66 m
Length Waterline (LWL):
5.08 m
Beam:
2.16 m
Draft (Max):
1.27 m
Draft (Min):
0.43 m
Weight & Ballast
Displacement:
635 kg
Ballast:
181 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
5.59 m²
Mainsail Area:
8.39 m²
Sail Area:
13.98 m²
Sail Area (reported):
13.98 m²
I (Fore Triangle Height):
5.94 m
J (Fore Triangle Base):
1.88 m
P (Mainsail Hoist):
6.48 m
E (Boom Length):
2.59 m
Est. Forestay Length:
6.23 m
Engine & Systems
Performance Ratios
Hull Speed:
5.47 knots
SA/Displacement (Calc):
19.28
SA/Displacement (Reported):
19.28
Ballast/Disp Ratio:
28.57%
Displacement/Length:
134.92
Comfort Ratio:
9.25
Capsize Screening:
2.53
S-Number:
3.94
Immersion:
75 kg/cm
Notes
Swing keel version of O'DAY 19.
