O'DAY 28
Built by Bangor Punta Marine (USA)
• Designed by C. Raymond Hunt and Associates
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1978
Last Built:
1986
Number Built:
544
Dimensions
Length Overall (LOA):
8.61 m
Length Waterline (LWL):
6.99 m
Beam:
3.12 m
Draft (Max):
1.37 m
Max Height:
12.22 m
Weight & Ballast
Displacement:
3,311 kg
Ballast:
1,066 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
20.20 m²
Mainsail Area:
14.17 m²
Sail Area:
34.37 m²
Sail Area (reported):
34.37 m²
I (Fore Triangle Height):
10.97 m
J (Fore Triangle Base):
3.68 m
P (Mainsail Hoist):
9.30 m
E (Boom Length):
3.05 m
Est. Forestay Length:
11.57 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Model:
12
Engine Power:
11 HP
Fuel Capacity:
68 L
Water Capacity:
95 L
Performance Ratios
Hull Speed:
6.42 knots
SA/Displacement (Calc):
15.78
SA/Displacement (Reported):
15.78
Ballast/Disp Ratio:
32.19%
Displacement/Length:
270.66
Comfort Ratio:
20.73
Capsize Screening:
2.12
S-Number:
1.88
Immersion:
150 kg/cm
Notes
A keel/cb verion of the the O'DAY 28 was also available. Draft BU: 3.25', BD: 6.83'; ballast: 2,725 lbs / 1,236 kg
