NIMBLE 20
Built by Nimble Boats (USA)
• Designed by Ted Brewer
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Fractionally Rigged Ketch
First Built:
1986
Dimensions
Length Overall (LOA):
6.38 m
Length Waterline (LWL):
6.02 m
Beam:
2.36 m
Draft (Max):
1.24 m
Draft (Min):
0.28 m
Weight & Ballast
Displacement:
841 kg
Ballast:
181 kg
Ballast Type:
Lead
Sail Plan
Sail Area (reported):
19.23 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.96 knots
SA/Displacement (Reported):
22.00
Ballast/Disp Ratio:
21.57%
Displacement/Length:
107.44
Comfort Ratio:
9.32
Capsize Screening:
2.53
Immersion:
98 kg/cm
Notes
Motor well in cockpit. Builder recommended 5 hp, standard shaft.
