MORGAN 54 (MARAUDER)
Built by Morgan Yacht Corp. (USA)
• Designed by Charles Morgan
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1969
Dimensions
Length Overall (LOA):
16.31 m
Length Waterline (LWL):
11.35 m
Beam:
3.81 m
Draft (Max):
2.34 m
Weight & Ballast
Displacement:
16,329 kg
Ballast:
7,257 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
61.83 m²
Mainsail Area:
47.22 m²
Sail Area:
109.04 m²
Sail Area (reported):
109.07 m²
I (Fore Triangle Height):
18.44 m
J (Fore Triangle Base):
6.71 m
P (Mainsail Hoist):
16.31 m
E (Boom Length):
5.79 m
Est. Forestay Length:
19.62 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Performance Ratios
Hull Speed:
8.18 knots
SA/Displacement (Calc):
17.30
SA/Displacement (Reported):
17.30
Ballast/Disp Ratio:
44.44%
Displacement/Length:
310.94
Comfort Ratio:
45.70
Capsize Screening:
1.52
S-Number:
1.69
Immersion:
297 kg/cm
Notes
Based on the 1968 racer 'Rage' (designed to the CCA rule). The boat was available in fixed keel and centerboard versions and in various stages of construction.
