MAXI 77
Built by Maxi Yachts / Börjesson Brothers
• Designed by Pelle Petterson
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
First Built:
1972
Last Built:
1983
Number Built:
3900
Dimensions
Length Overall (LOA):
7.70 m
Length Waterline (LWL):
6.75 m
Beam:
2.50 m
Draft (Max):
1.45 m
Weight & Ballast
Displacement:
2,000 kg
Ballast:
800 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
15.30 m²
Mainsail Area:
9.37 m²
Sail Area:
24.67 m²
Sail Area (reported):
25.00 m²
I (Fore Triangle Height):
9.17 m
J (Fore Triangle Base):
3.33 m
P (Mainsail Hoist):
7.50 m
E (Boom Length):
2.50 m
Est. Forestay Length:
9.76 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Gas
Engine Model:
MB-10/100s
Engine Power:
15 HP
Fuel Capacity:
20 L
Performance Ratios
Hull Speed:
6.31 knots
SA/Displacement (Calc):
15.85
SA/Displacement (Reported):
16.06
Ballast/Disp Ratio:
40.01%
Displacement/Length:
181.12
Comfort Ratio:
17.90
Capsize Screening:
2.00
S-Number:
2.79
Immersion:
116 kg/cm
Notes
As best as can be determined, this was the most popular Maxi with an amazing 3900 sold!
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
