LN-23 (LOCKLEY-NEWPORT)
Built by Lockley-Newport Boats (USA)
• Designed by Stuart Windley
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Fractional Sloop
First Built:
1978
Dimensions
Length Overall (LOA):
6.96 m
Length Waterline (LWL):
6.10 m
Beam:
2.44 m
Draft (Max):
1.68 m
Draft (Min):
0.59 m
Max Height:
9.91 m
Weight & Ballast
Displacement:
1,225 kg
Ballast:
454 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
11.55 m²
Mainsail Area:
10.35 m²
Sail Area:
21.90 m²
Sail Area (reported):
26.76 m²
I (Fore Triangle Height):
7.77 m
J (Fore Triangle Base):
2.97 m
P (Mainsail Hoist):
7.54 m
E (Boom Length):
2.74 m
Est. Forestay Length:
8.32 m
Engine & Systems
Water Capacity:
38 L
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calc):
19.50
SA/Displacement (Reported):
23.82
Ballast/Disp Ratio:
37.04%
Displacement/Length:
150.67
Comfort Ratio:
12.54
Capsize Screening:
2.30
S-Number:
3.71
Immersion:
102 kg/cm
Notes
Later became the GLOUCESTER 22, and then CLASSIC 22.
