LADY HELMSMAN
Built by Helmsman Yachts
• Designed by Håkan Södergren
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Fractional Sloop
First Built:
1976
Number Built:
200
Dimensions
Length Overall (LOA):
12.10 m
Length Waterline (LWL):
9.48 m
Beam:
2.51 m
Draft (Max):
1.75 m
Weight & Ballast
Displacement:
4,700 kg
Ballast:
2,235 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
19.62 m²
Mainsail Area:
24.14 m²
Sail Area:
43.75 m²
Sail Area (reported):
43.76 m²
I (Fore Triangle Height):
11.05 m
J (Fore Triangle Base):
3.55 m
P (Mainsail Hoist):
12.70 m
E (Boom Length):
3.80 m
Est. Forestay Length:
11.61 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
MD7A
Engine Power:
13 HP
Performance Ratios
Hull Speed:
7.47 knots
SA/Displacement (Calc):
15.91
SA/Displacement (Reported):
15.91
Ballast/Disp Ratio:
47.56%
Displacement/Length:
153.77
Comfort Ratio:
28.59
Capsize Screening:
1.52
S-Number:
3.15
Immersion:
164 kg/cm
Notes
In the late 1980s a 'GT'-version was offered, with a taller mast, and a modified rudder. The original model but with a taller rig is known as the LADY HELMSMAN II.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
